VEHICLE APPLICATION LIBRARY

Ford lift support references

Browse Ford hood, trunk, liftgate and rear-glass application references by model, year and support position. Select a reference and send your quantities for a supply quotation.

All vehicle makes →
Find the reference you needChoose a filter or enter a complete part number.
178 published references

Published application references help identify your request. They are not Horizon stock codes. Confirm the exact assembly, fittings and quantity in your quotation. Unpublished specifications are left open for matching.

Vehicle applications: StrongArm 2023 reference edition. Dimensions, where shown, are from the linked official product page. Check equipment and production-date conditions for your vehicle.

StrongArm E6484

Ford F-150 2009–2014 Hood

2009–2014 · Hood · Quantity per vehicle: 2

Published specifications

Extended: 364.24 mm / 14.34 in
Compressed: 237.24 mm / 9.34 in
Stroke: 127 mm / 5.00 in
Maximum force: 458.17 N / 103 lbf
Tube / rod diameter: 19 / 8 mm
End 1: Ball Socket; source size 10 mm / 0.39 in; End 2: Ball Socket; source size 8 mm / 0.31 in

Quote this reference →Application source ↗Dimensions & force source ↗
StrongArm D4153

Ford F-150 2005–2008 Hood

2005–2008 · Hood · Quantity per vehicle: 2

Published specifications

Extended: 400.3 mm / 15.76 in
Compressed: 260.6 mm / 10.26 in
Stroke: 139.7 mm / 5.50 in
Maximum force: 373.65 N / 84 lbf
Tube / rod diameter: 15 / 6 mm
End 1: Ball Socket 16 Deg.; End 2: Ball Socket; source size 8 mm / 0.31 in

Quote this reference →Application source ↗Dimensions & force source ↗
StrongArm C4271

Ford Aerostar 1987–1987 Liftgate

1987 · Liftgate · Quantity per vehicle: 2

From 05/1987; without Rear Wiper

Assembly matching

Match dimensions from the original assembly

Quote this reference →Application source ↗
StrongArm D4423

Ford Bronco II 1984–1990 Back Glass

1984–1990 · Back Glass · Quantity per vehicle: 2

with Movable Rear Window

Assembly matching

Match dimensions from the original assembly

Quote this reference →Application source ↗
StrongArm B6686

Ford Escape 2013–2017 Tailgate

2013–2017 · Tailgate · Quantity per vehicle: 1

Left; without Power Lift Gate

Assembly matching

Match dimensions from the original assembly

Quote this reference →Application source ↗
StrongArm B6687

Ford Escape 2013–2017 Tailgate

2013–2017 · Tailgate · Quantity per vehicle: 1

Right; without Power Lift Gate

Assembly matching

Match dimensions from the original assembly

Quote this reference →Application source ↗
StrongArm D4649

Ford Escort 1993–1996 Tailgate

1993–1996 · Tailgate · Quantity per vehicle: 2

Wagon; 4-Door; without Rear Wiper

Assembly matching

Match dimensions from the original assembly

Quote this reference →Application source ↗
StrongArm D4372

Ford Explorer 2002–2003 Back Glass

2002–2003 · Back Glass · Quantity per vehicle: 2

From 03/04/2002; To 05/05/2003

Assembly matching

Match dimensions from the original assembly

Quote this reference →Application source ↗
StrongArm E6862

Ford F-150 2015–2020 Hood

2015–2020 · Hood · Quantity per vehicle: 1

Right

Published specifications

Extended: 388.87 mm / 15.31 in
Compressed: 249.17 mm / 9.81 in
Stroke: 139.7 mm / 5.50 in
Maximum force: 226.86 N / 51 lbf
Tube / rod diameter: 18 / 8 mm
End 1: Ball Socket; source size 10 mm / 0.39 in; End 2: Ball Socket; source size 8 mm / 0.31 in

Quote this reference →Application source ↗Dimensions & force source ↗
StrongArm C6246

Ford Flex 2009–2016 Liftgate, Gas Charged

2009–2016 · Liftgate, Gas Charged · Quantity per vehicle: 2

with Power Lift Gate

Assembly matching

Match dimensions from the original assembly

Quote this reference →Application source ↗
StrongArm E6436

Ford Focus 2000–2000 Trunk Lid

2000 · Trunk Lid · Quantity per vehicle: 2

Sony Limited Edition; without Spoiler

Assembly matching

Match dimensions from the original assembly

Quote this reference →Application source ↗
StrongArm C6447

Ford Freestar 2004–2007 Liftgate, Gas Charged

2004–2007 · Liftgate, Gas Charged · Quantity per vehicle: 2

with Power Lift Gate

Assembly matching

Match dimensions from the original assembly

Quote this reference →Application source ↗
StrongArm E6393

Ford Fusion 2007–2009 Trunk Lid

2007–2009 · Trunk Lid · Quantity per vehicle: 2

From 07/16/2007; with Spoiler

Assembly matching

Match dimensions from the original assembly

Quote this reference →Application source ↗
StrongArm E6671

Ford Fusion 2006–2007 Trunk Lid

2006–2007 · Trunk Lid · Quantity per vehicle: 2

From 08/30/2006; To 07/16/2007; with Spoiler

Assembly matching

Match dimensions from the original assembly

Quote this reference →Application source ↗
StrongArm E6862

Ford Lobo 2015–2020 Hood

2015–2020 · Hood · Quantity per vehicle: 1

Right

Published specifications

Extended: 388.87 mm / 15.31 in
Compressed: 249.17 mm / 9.81 in
Stroke: 139.7 mm / 5.50 in
Maximum force: 226.86 N / 51 lbf
Tube / rod diameter: 18 / 8 mm
End 1: Ball Socket; source size 10 mm / 0.39 in; End 2: Ball Socket; source size 8 mm / 0.31 in

Quote this reference →Application source ↗Dimensions & force source ↗
StrongArm E7129

Ford Mustang 2015–2020 Deck Lid

2015–2020 · Deck Lid · Quantity per vehicle: 2

Convertible; 2-Door; without Spoiler

Assembly matching

Match dimensions from the original assembly

Quote this reference →Application source ↗
StrongArm E6559

Ford Police Interceptor Sedan 2013–2019 Trunk Lid

2013–2019 · Trunk Lid · Quantity per vehicle: 2

with Spoiler

Assembly matching

Match dimensions from the original assembly

Quote this reference →Application source ↗
StrongArm E6549

Ford Police Interceptor Sedan 2013–2019 Trunk Lid

2013–2019 · Trunk Lid · Quantity per vehicle: 2

without Spoiler

Assembly matching

Match dimensions from the original assembly

Quote this reference →Application source ↗
StrongArm C6681

Ford Police Interceptor Utility 2013–2015 Hatch

2013–2015 · Hatch · Quantity per vehicle: 1

without Power Lift Gate

Assembly matching

Match dimensions from the original assembly

Quote this reference →Application source ↗
StrongArm C4836

Ford Probe 1989–1992 Hatch

1989–1992 · Hatch · Quantity per vehicle: 1

Left; without Spoiler; without Wiper

Assembly matching

Match dimensions from the original assembly

Quote this reference →Application source ↗
StrongArm C4835

Ford Probe 1989–1992 Hatch

1989–1992 · Hatch · Quantity per vehicle: 1

Right; without Spoiler; without Wiper

Assembly matching

Match dimensions from the original assembly

Quote this reference →Application source ↗
StrongArm E6559

Ford Special Service Police 2015–2018 Trunk Lid

2015–2018 · Trunk Lid · Quantity per vehicle: 2

with Spoiler

Assembly matching

Match dimensions from the original assembly

Quote this reference →Application source ↗
StrongArm E6549

Ford Special Service Police 2015–2018 Trunk Lid

2015–2018 · Trunk Lid · Quantity per vehicle: 2

without Spoiler

Assembly matching

Match dimensions from the original assembly

Quote this reference →Application source ↗
StrongArm D4601

Ford Taurus 1986–1995 Tailgate

1986–1995 · Tailgate · Quantity per vehicle: 2

Wagon; 4-Door

Published specifications

Extended: 460.5 mm / 18.13 in
Compressed: 284.23 mm / 11.19 in
Stroke: 176.28 mm / 6.94 in
Maximum force: 627.2 N / 141 lbf
Tube / rod diameter: 22 / 8 mm
End 1: Ball Socket; source size 10 mm / 0.39 in; End 2: Ball Socket; source size 8 mm / 0.31 in

Quote this reference →Application source ↗Dimensions & force source ↗
StrongArm C4559

Ford Windstar 1999–2003 Liftgate

1999–2003 · Liftgate · Quantity per vehicle: 2

Published specifications

Extended: 625.09 mm / 24.61 in
Compressed: 374.4 mm / 14.74 in
Stroke: 250.7 mm / 9.87 in
Maximum force: 725.06 N / 163 lbf
Tube / rod diameter: 22 / 8 mm
End 1: Ball Socket; source size 10 mm / 0.39 in; End 2: Ball Socket; source size 10 mm / 0.39 in

Quote this reference →Application source ↗Dimensions & force source ↗
